2.0 Telescopic Ram

Shop our extensive safety kits today and ensure readiness for any situation! Buy the 2.0 Telescopic Ram at safetykitsusa.shop.

Contact the e-Fire Sales Team for Pricing!

Introducing the 22-54 Telescopic Eforce 2.0 Ram, a two-staged telescopic ram representing the next generation of untethered extrication. Genesis spearheaded the redesign, starting with the drive unit, which now features a brushless motor for enhanced power. Encased in a state-of-the-art housing crafted from impact-resistant polymer, this ram delivers exceptional durability.

The redesigned drive unit allows for extended run time with the M28 battery, nearly doubling its previous capacity. For those seeking additional batteries, they are available here.

The heart of the drive unit features a brushless motor with neodymium magnets and a rotating case manufactured using cutting-edge technology and premium materials. Supported by three ball bearings, the hardened steel 5/16-inch shaft ensures robust construction and long service life.

Specifications:

• 22-54 Telescopic Eforce 2.0 Telescopic Ram
• Length Closed:   23.1″ / 586 mm
• Width:  5.3″ / 134 mm
• Height:  13.7 / 349 mm
• Weight:  44.3 lbs. / 20.1 kg
• Stroke Stage 1:  16.9″ / 428 mm
• Stroke Stage 2:  14.6″ / 372 mm
• Length Extended:  54.6″ / 1386 mm
• Ingress Protection Rating: IP54
• Force Stage 1:  24,300 lbf / 108 kN
• Force Stage 2:  13,950 lbf / 62 kN
• Nominal Pressure:  550 bar / 7,975 psi

Note:  Shipping and Handling Fees
Please be aware that this product ships via freight truck, so shipping and handling fees are estimated only. For an exact shipping charge, please contact the e-Fire Sales Team and we’ll provide you with a quote.
